The SDA Series Compact Cylinder is engineered for industrial automation systems requiring reliable linear motion within limited installation space. Its compact riveted construction provides excellent structural integrity while reducing overall cylinder dimensions.
Featuring a hard anodized aluminum barrel, advanced two-way piston sealing technology, and integrated magnetic switch grooves, the SDA Series offers long service life, stable operation, and convenient sensor installation for modern automation equipment.
The SDA Series Compact Cylinder is a space-saving pneumatic actuator designed to deliver reliable performance in compact automation systems. Its integrated riveted construction creates a robust and compact assembly, helping reduce installation space while maintaining excellent mechanical strength.
Designed for long-term industrial operation, the cylinder combines wear-resistant materials, advanced sealing technology, and convenient sensor integration to meet the demands of modern manufacturing equipment.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
● Compact integrated cylinder design
● Riveted body construction for improved reliability
● Hard anodized aluminum barrel
● High-performance two-way piston seal
● Built-in grease retention design
● Integrated magnetic switch grooves
● Excellent wear resistance
● Durable and stable operation
● Multiple mounting accessories available
● Suitable for compact automation systems
● Compact and Reliable Construction
The SDA Series adopts a riveted structure that securely connects the cylinder body with the rear cover, while the piston and piston rod are also integrated into a compact assembly.
This design provides several advantages:
● Reduced overall dimensions
● Improved structural rigidity
● Enhanced operational reliability
● Stable long-term performance
● Simplified machine installation
The compact body makes the cylinder particularly suitable for equipment with limited installation space.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
The inner surface of the cylinder barrel undergoes precision rolling followed by a hard anodizing process, creating a highly wear-resistant working surface.
This treatment offers:
● Excellent abrasion resistance
● Improved corrosion protection
● Longer service life
● Smooth piston movement
● Reliable operation under continuous cycling
The piston incorporates a heterogeneous two-way sealing structure that combines compact dimensions with effective grease retention, helping reduce friction and extend seal life.
High-quality sealing components further contribute to stable pneumatic performance and reduced maintenance requirements.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
Magnetic switch grooves are integrated around the cylinder body, allowing sensors to be installed quickly without additional brackets or modifications.
This design simplifies automation system integration and supports:
● Position detection
● Process monitoring
● PLC control systems
● Automated production equipment
● Improved operational efficiency
The sensor-ready construction makes the SDA Series suitable for intelligent manufacturing applications.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
Various mounting accessories are available to accommodate different equipment designs and installation requirements.
The SDA Series Compact Cylinder is widely used in:
● Packaging machinery
● Electronics assembly
● Conveyor automation
● Pick-and-place equipment
● Textile machinery
● Medical devices
● Food processing equipment
● Material handling systems
● OEM automation equipment
● General industrial automation
Its compact structure, durable barrel construction, advanced sealing technology, and integrated sensor slots make the SDA Series a practical solution for precision pneumatic motion control.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
The SDA Series Compact Cylinder is designed for modern automation systems requiring compact dimensions, dependable operation, and easy sensor integration.
Combining a riveted compact structure, hard anodized barrel, advanced piston sealing, and flexible mounting options, the SDA Series delivers efficient and reliable pneumatic performance for a wide range of industrial applications.
