The CJP Series Pin Cylinder (Single Acting) is a compact pneumatic actuator designed for positioning, indexing, locking, and stop mechanisms in automated machinery. Utilizing a spring-return structure, it delivers reliable linear motion while minimizing air consumption and simplifying control systems.
With its miniature dimensions, durable construction, and maintenance-free operation, the CJP Series is an ideal solution for precision automation equipment where installation space is limited and accurate positioning is required.
The CJP Series Pin Cylinder is specifically developed for applications that require precise positioning and locking functions within a compact installation space. Its single-acting spring-return design ensures dependable operation while reducing pneumatic circuit complexity and compressed air usage.
Available in small bore sizes ranging from Ø6 mm to Ø15 mm, the CJP Series is well suited for lightweight automation tasks that require accurate and repeatable motion.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
● Compact pin cylinder design
● Single acting spring-return operation
● Small bore sizes from Ø6 to Ø15 mm
● Low air consumption
● Precision positioning capability
● Maintenance-free non-lube design
● Compact panel-mount installation
● Stable and repeatable operation
● Fast response characteristics
● Suitable for space-constrained equipment
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
Unlike conventional mini cylinders, the CJP Series is optimized for positioning and stop functions. The integrated spring-return mechanism automatically resets the piston when air pressure is removed, making it ideal for indexing devices, workpiece location systems, and locking mechanisms.
Its compact structure allows installation in machinery where available mounting space is extremely limited.
| Parameter | Specification |
| Bore Size | 20–100 mm |
| Action Type | Double Acting |
| Working Medium | Air |
| Operating Pressure | 0.05–1.0 MPa |
| Piston Speed | 50–1000 mm/s |
| Cushion Type | Rubber Bumper / Air Cushion |
| Lubrication | Non-Lube |
| Port Size | Rc1/8 – Rc1/2 |
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
The CJP Series operates without external lubrication under normal conditions, helping reduce maintenance requirements and operating costs. Its simple pneumatic structure improves reliability and supports long-term operation in repetitive automation processes.
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
The CJP Series Pin Cylinder is widely used in:
● Positioning fixtures
● Indexing mechanisms
● Workpiece locating systems
● Conveyor stop units
● Packaging equipment
● Electronics assembly machinery
● Small automation devices
● Sorting systems
● Testing equipment
● OEM industrial machinery
Combining compact dimensions, spring-return functionality, and precise positioning performance, the CJP Series Pin Cylinder offers an efficient solution for modern automation and machine design.
