The SPCF and SPCF-G Series Stainless Steel Push-in Fittings are manufactured from high-quality stainless steel materials, providing excellent corrosion resistance, mechanical strength, and long-lasting performance in pneumatic applications. Available in 303, 304, 316, and 316L stainless steel, they are suitable for demanding industrial environments.
Designed with a female straight structure, these stainless steel push-in fittings enable convenient connection between pneumatic tubes and threaded components. With precise machining, multiple thread standards, and reliable sealing performance, they are widely used in automation equipment, pneumatic control systems, and applications requiring clean and durable connections.
The SPCF and SPCF-G Series Stainless Steel Push-in Fittings are designed for pneumatic systems that require compact structure, high reliability, and excellent corrosion resistance. Featuring a female straight design, these fittings provide a convenient solution for connecting pneumatic tubes with internally threaded ports while maintaining stable airflow performance.
Manufactured from premium stainless steel materials, the fittings offer outstanding resistance to corrosion, moisture, and harsh working environments. The SPCF-G series adopts an enhanced sealing structure to further improve connection stability and reduce potential leakage during long-term operation.
Each stainless steel push-in fitting is produced under strict quality control to ensure consistent dimensions and reliable performance. Automated manufacturing equipment is used for most production processes, while key procedures are inspected by professional technicians to meet precise tolerance requirements.
• Available materials: 303, 304, 316, and 316L stainless steel.
• Multiple thread options including BSP, PT, NPT, and metric threads.
• Support OEM and ODM customization with CAD drawings available.
• Ultrasonic cleaning and drying process before shipment.
• Certified according to ISO9001, CE, and FDA standards.
The push-in connection mechanism allows quick and simple tube installation without additional tools. Users can directly insert the pneumatic tube into the fitting to achieve a secure connection, improving assembly efficiency and reducing maintenance time.
SPCF and SPCF-G Series Female Straight Stainless Steel Push-in Fittings are widely applied in industrial automation, pneumatic machinery, packaging equipment, food processing systems, and other industries where corrosion resistance and hygienic connection solutions are required.
With flexible configurations and dependable performance, these fittings provide an efficient connection choice for various pneumatic applications.
